Working process
Vial inlet by turntable – soaking in ultrasonic water tank – air blowing – pure water rinsing – air blowing – WFI rinsing – air blowing – vial outlet
Advantages
- Round corner without dead end.
- Comply to GMP requirement.
- Soaking time ≥ 7 seconds.
- Inside and outside rinsing.
- Individual drive for vial unscrambling turntable and vial feeding dialing wheels.
- Combination type bearing device, rotating bearing system with frequency convertor.
- Vial feeding tracks are made of 3mm thick SUS304.
| Model | XP1/2/3/4/5/6 |
| Production capacity | 50-400vpm |
| Applicable vials | 7~20ml vials |
| Washing mode | Ultrasonic washing, rinsing, air blowing |
| Washing efficiency | Comply to GMP, no visual spot or glass shavings.
Residual water ≤1 drop/vial |
| Broken rate | ≤0.01% |
| Dimension | 2800×700×1800mm (2 tracks) |
| Power supply | 380V/50Hz, 3P, 5 wires |
